4.9.3 Function Code Configurator – Advanced
Configuration
This tab allows you to specify the function code list for the DPI Modbus
Enforcer rule by entering a series of function code numbers.
You can find the meaning of the "Function Code" numbers in section
“Meaning of the Function Code values” on page 168.
Possible values:
1,2,3,4,7,11,12,17,20,24
(default setting for "Function Code" =
readonly
)
1,2,3,4,5,6,7,11,12,15,16,17,20,21,22,23,24
(default setting for "Function Code" =
readwrite
)
1,2,3,4,5,6,7,11,12,15,16,17,20,21,22,23,24,40,42,90,125,
126
(default setting for "Function Code" =
programming
)
1,2,..,255
(default setting for "Function Code" =
all
)
<1,2,..,255>|<0..65535>|<0..65535>
Function codes
<1,2,..,255>
, read address range
<0..65535>
and
write address range
<0..65535>
.
– You separate multiple function codes with a comma.
Example:
1,23,24
– You separate the function code and the address range with a vertical
line. You enter the address range with minus signs.
Example:
1|128-255,23|512-1023|2048-2051,42
"Function Code" =
1
with coil address range
128..255
"Function Code" =
23
with read register address range
512..1023
and
write register address range
2048..2051
"Function Code" =
42
.
Buttons
Button Meaning
Ok Closes the "Create" window and transfers the changes to the volatile
memory (
RAM
) of the device.
Cancel Closes the "Create" window without saving the changes.
