Network Security > ACL > IPv4 Rule
Network Security
RM GUI HiSecOS EAGLE20/30
Release 3.0 09/2015
189
TOS Priority Specifies the IP precedence (ToS value) in the header of the IP data
packets to which the device applies the rule.
Possible values:
 any (default setting)
The device applies the rule to every IP data packet without
considering the ToS value.
 0..7
The device applies the rule solely to IP data packets containing the
specified ToS value.
TOS Mask Specifies the bit mask for the ToS value in the header of the IP data
packets to which the device applies the rule. Prerequisite is that you
specify in the "TOS Priority" field a ToS value.
Possible values:
 any (default setting)
The device applies the rule to IP data packets and considers the ToS
value completely.
 1..1f
The device applies the rule to IP data packets and considers the bits
of the ToS value specified in the bit mask.
Packet fragmented Activates/deactivates applying the ACL rule to fragmented packets.
Possible values:
 marked
The device applies the ACL rule to fragmented packets.
 unmarked (default setting)
Matching is inactive.
Action Specifies how the device handles received IP data packets when it applies
the rule.
Possible values:
 permit (default setting)
The device transmits the IP data packets.
 deny
The device drops the IP data packets.
Redirection Port Specifies the port on which the device transmits the IP data packets. The
prerequisite is that you specify in the "Action" field the value
permit .
Possible values:
 any (default setting)
The device transmits the IP data packets on every port.
 <Port number>
The device transmits the IP data packets on the specified port.
The device does not provide the option of transmitting IP data packets
across VLAN boundaries or to routing interfaces.
Parameters Meaning
