Routing > Routing Table
Routing
RM GUI HiSecOS EAGLE20/30
Release
3.0
09/2015
349
Create Opens the "Create" dialog to create a static route.
Drop-down list
Here you specify the type of the new route.
Possible values:
–
custom
Creates a static route. All fields are editable.
–
default
Creates a default route. The value in the fields "Network Address"
and "Netmask" is fixed.
–
reject
Creates a reject route. The value in the "Next Hop IP Address"
field is fixed.
Network Address field
You specify the address of the destination network here.
Possible values:
– Valid IPv4 address
Netmask field
Here you can specify the network mask that identifies the network
prefix in the address of the destination network.
Possible values:
– Valid IPv4 netmask
Next Hop IP Address field
Here you specify the IP address of the next router on the path to the
destination network.
Possible values:
– Valid IPv4 address
Preference field
Here you can specify the preference number that the device uses to
decide which of several existing routes to the destination network it will
use.
Possible values:
–
1..255
In routing decisions, the device gives preference to the route with
the smallest value. The default is the value specified in the
"Configuration" frame, field "Preference".
Track Name field
Here you can specify the tracking object with which the device links
the route.
Possible values:
– Name of the tracking object, made up of "Type" and "Track ID".
–
–
No tracking object selected.
Remove Removes the highlighted table entry.
Help Opens the online help.
Button Meaning
