Installation MS20/MS30
Release
11
07/2013
55
Figure 26: Dimensions of media modules
115
4.53
MM... 48 V
94
73
mm
inch
MM... 24 V
136
5.35
133
3.7
2.87
5.24
38
1.5
133
5.24
38
1.5
