18
Installation MS20/MS30
Release
11
07/2013
For the sake of simplicity, the basic switch module with various plugged in
media modules will be referred to as MICE in this document.
The MS20-... device variants are modular switches with up to 8, 16 or
24 * 10/100 Mbit/s Ethernet ports. You can choose the media for the ports
via the media modules.
The MS30-... device variants are modular switches with up to 8, 16 or
24 * 10/100 Mbit/s Ethernet ports and up to 2 additional Gigabit ports
(1000 Mbit/s Ethernet). You can choose the media for the ports via the
media modules.
The basic module of the MS20/MS30 contains all the function units, such as:
switch function, management function, redundancy function, display control,
voltage connection, management connection, adjustable controls, slots for
media modules.
1.3.1 Number of ports and connections
Device versions with 10/100 Mbit/s ports
MS20-0800..., MS20-1600..., MS20-2400...
Depending on the variant, the MS20 basic modules provide you with the
following number of slots for media modules and the following maximum
number of connectable network segments:
Family Designed for
MS20 Larger numbers of ports, number of 100 Mbit ports desired, temperature range,
voltage range, certificates and software variant can be selected.
MS30 Larger numbers of ports and larger bandwidth requirement,
number of 100/1000 Mbit ports desired, temperature range, voltage range,
certificates and software variant can be selected.
Basic module Number of slots for
10/100 Mbit/s media
modules
Max. possible number of connectible
10/100 Mbit/s network segments when
connecting 4-port media modules
MS20-0800... 2 8
MS20-1600... 4 16
a
a. Can be expanded to 24 ports with the MB20 extender module
MS20-2400... 6 24
