62
Installation MS20/MS30
Release
11
07/2013
MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul
Basic modules: Power consumption/Power output,
Operating voltage
Note: For the extended temperature range, use suitable modules and
transceivers. You will identify these components by the “EEC” name
extension or the open variant product code “E” (postion 15).
Product
code
M-SFP-
BIDI...
Wave
length
TX
Wave
length
RX
Fiber System
attenuat
ion
Example
for F/O
line
length
a
a. including 3 dB system reserve when compliance with the fiber data is observed
Fiber
attenuati
on
Dispersion
Type A
LX/LC
EEC
SM 1310 nm 1550 nm 9/125 µm 0-11 dB 0-20 km 0.4 dB/km 3.5
ps/(nm×km)
Type B
LX/LC
EEC
SM 1550 nm 1310 nm 9/125 µm 0-11 dB 0-20 km 0.25
dB/km
19 ps/(nm×km)
Type A
LH/LC
EEC
LH 1490 nm 1590 nm 9/125 µm 5-24 dB 23-80 km 0.25
dB/km
19 ps/(nm×km)
Type B
LH/LC
EEC
LH 1590 nm 1490 nm 9/125 µm 5-24 dB 23-80 km 0.25
dB/km
19 ps/(nm×km)
Table 21: F/O port (bidirectional Gigabit Ethernet SFP Transceiver)
Basic module Power consumption Power output Operating voltage
MS20-0800...A... 5.0 W 17.1 Btu (IT)/h 18-32 V DC
MS20-0800...C...
MS20-0800...E...
7.4 W 25.4 Btu (IT)/h 18-60 V DC
MS30-0802...A... 5.6 W 19.2 Btu (IT)/h 18-32 V DC
MS30-0802...C...
MS20-0800...E...
8.6 W 29.6 Btu (IT)/h 18-60 V DC
MS20-1600...A... 12.0 W 40.0 Btu (IT)/h 18-32 V DC
MS20-1600...C...
MS20-0800...E...
15.6 W 52.2 Btu (IT)/h 18-60 V DC
MS30-1602...A... 12.6 W 41.1 Btu (IT)/h 18-32 V DC
MS30-1602...C...
MS20-0800...E...
16.8 W 56.7 Btu (IT)/h 18-60 V DC
MS20-2400...A... 12.0 W 40.0 Btu (IT)/h 18-32 V DC
MS20-2400...C...
MS20-0800...E...
16.8 W 56.7 Btu (IT)/h 18-60 V DC
MS30-2402...A... 12.6 W 42.1 Btu (IT)/h 18-32 V DC
MS30-2402...C...
MS20-0800...E...
18.0 W 60.9 Btu (IT)/h 18-60 V DC
