Installation MS20/MS30
Release
11
07/2013
Open variant product code
As an alternative to the order number (see in table 22, last column) you
can use the product code. This gives you a wider range of variants when
selecting the media module that is specially tailored to your requirements.
The product code of your media module is made from combining the
desired product characteristics in accordance with the following table.
The short designation is in "Ident." column.
Example: Product code MM30-O7O7O7O7SA = media module
1000 Mbit/s with four Gigabit Ethernet combo ports (four SFP ports or
alternatively TP ports RJ45). This example corresponds to the
MM4-4TX/SFP module with the order number 943 010-001.
MM22-T1T1T1T1...
- internal operating voltage
- external PoE voltage
- no PD
- 4 x Class0-PD
0.8 W
1.3 W
2 W + PDs
2.8 Btu (IT)/h
4.3 Btu (IT)/h
6.9 Btu (IT)/h
- “ - - “ -
MM23-T1T1T1T1...SAHH 4,5 W 15,4 Btu (IT)/h 0 °C ... +60 °C - “ -
MM23-M2M2T1T1...SAHH 6,0 W 20,5 Btu (IT)/h 0 °C ... +60 °C - “ -
MM23-S2S2T1T1...SAHH 5,5 W 18,8 Btu (IT)/h 0 °C ... +60 °C - “ -
MM23-F4F4T1T1...SAHH 5,5 W 18,8 Btu (IT)/h 0 °C ... +60 °C - “ -
MM24-IOIOIOIO... 7,5 W 25,6 Btu (IT)/h 0°C ... +60 °C - “ -
MM30-O7O7O7O7... 9,0 W 30,8 Btu (IT)/h See table 23. - “ -
MM30-O7O79999... 5,8 W 19,8 Btu (IT)/h - “ - - “ -
MM33-O7O79999...SAHH 7,5 W 25,6 Btu (IT)/h 0 °C ... +60 °C - “ -
Extender module:
MB20 0 W 0 Btu (IT)/h 0 °C to +60 °C 943 733-102
Item Characteristic feature Ident. Property
1 to 4 Product MM20 Media module 10/100 Mbit/s (standard)
MM22 Media module 10/100 Mbit/s (Power over
Ethernet)
MM23 Media module 10/100 Mbit/s (PTP version 2)
MM30 Media module 1000 Mbit/s (standard)
MM33 Media module 1000 Mbit/s (PTP version 2)
5 - (hyphen) -
Table 23: Combination possibilities of the MM20/MM30 media module variants
Module Power
consumpti
on
Power output Operating
temperature
(ambient air
temperature)
Order
number
Table 22: Media modules: power, temperature, order numbers
