Installation RSP 20/25/30/35
Release 15 12/2017
17 Temperature range S Standard +32 °F ... +140 °F
(0 °C ... +60 °C)
T Extended −40 °F ... +158 °F
(−40 °C ... +70 °C)
E Extended with
Conformal Coating
−40 °F ... +158 °F
(−40 °C ... +70 °C)
18 ... 19 Supply voltage CC 2 voltage inputs for redundant power supply
Rated voltage range DC
24 V DC ... 48 V DC
K9 1 voltage input
Rated voltage range AC
110 V AC ... 230 V AC, 50 Hz ... 60 Hz
Rated voltage range DC
60 V DC ... 250 V DC
KK 2 voltage inputs for redundant power supply
Rated voltage range AC
110 V AC ... 230 V AC, 50 Hz ... 60 Hz
Rated voltage range DC
60 V DC ... 250 V DC
TT 2 voltage inputs for redundant power supply
Rated voltage range DC
12 V DC ... 24 V DC
20 ... 21 Certificates and
declarations
You will find detailed information on the certificates and
declarations applying to your device in a separate overview.
See table 5 on page 21.
22 ... 23 Customer-specific
version
HS Hirschmann Standard
HM Hirschmann Fast MRP
HP Hirschmann PRP
HH Hirschmann HSR
HD From software version 05.0 onward:
Hirschmann DLR
Note: You can exchange software with each other on the
following device variants:
 HM
 HP
 HH
24 Software
configuration
E Entry (without configuration)
25 ... 26 Software level 2S HiOS Layer 2 Standard
2A HiOS Layer 2 Advanced
3S HiOS Layer 3 Standard
27 ... 31 Software version 02.0. Software version 02.0
XX.X. Current software version
Item Characteristic Character
istic value
Description
Table 4: Device name and product code
