32
Installation RSP 20/25/30/35
Release
15
12/2017
2.2 Installing the SD card (optional)
Note: Only use the AutoConfiguration Adapter ACA31 storage medium.
See “Accessories” on page 60.
Proceed as follows:
Deactivate the write protection on the SD card by pushing the write-
protect lock towards the middle of the card.
Push the SD card into the slot with the beveled corner facing upwards.
Tighten the thumb screw hand-tight to fix the SD card.
2.3 Installing and grounding the device
WARNING
FIRE HAZARD
Install the device in a fire enclosure according to EN 60950-1.
Failure to follow this instruction can result in death, serious injury, or
equipment damage.
WARNING
ELECTRIC SHOCK
Install this device solely in a switch cabinet or in an operating site with
restricted access, to which maintenance staff have exclusive access.
Failure to follow this instruction can result in death, serious injury, or
equipment damage.
