Installation RSP 20/25/30/35
Release
15
12/2017
41
2.5.5 Signal contact
Connect the signal contact wires with the connectors of the terminal block.
Fasten the wires connected by tightening the terminal screws.
You find the prescribed tightening torque in chapter:
“General technical data” on page 49
2.6 Operating the device
Relevant for North America:
You find the prescribed tightening torque in chapter:
“General technical data” on page 49
Proceed as follows:
Use screws to secure the connectors to the device.
Enable the supply voltage.
WARNING
ELECTRIC SHOCK
Before connecting the electrical wires, always verify that the requirements
listed are complied with.
See “Requirements for connecting electrical wires” on page 6.
Ground the device before connecting any other cables.
Failure to follow this instruction can result in death, serious injury, or
equipment damage.
