54
Installation RSP 20/25/30/35
Release
15
12/2017
8.4 EMC and immunity
You will find detailed information on the certificates and declarations applying to your device in a separate overview.
See table 5 on page 21.
Stability Standard applications Substation applications
IEC 60068-2-6, test Fc Vibration 2 Hz ... 9 Hz with 0.12 in. (3 mm)
amplitude
5 Hz ... 8.4 Hz with 0.14 in. (3.5 mm)
amplitude
5 Hz ... 8.4 Hz with 0.14 in. (3.5 mm)
amplitude
8.4 Hz ... 150 Hz
with 1 g
9 Hz ... 200 Hz
with 1 g
200 Hz ... 500 Hz
with 1,5 g
IEC 60068-2-27, test Ea Shock 15 g at 11 ms 15 g at 11 ms
EMC interference emission Standard applications Substation applications
Radiated emission
EN 55032 Class A Class A
GL Guidelines ——
FCC 47 CFR Part 15 Class A Class A
EN 61000-6-4 Fulfilled Fulfilled
Conducted emission
EN 55032 AC and DC supply connections Class A Class A
GL Guidelines AC and DC supply connections
FCC 47 CFR Part 15 AC and DC supply connections Class A Class A
EN 61000-6-4 AC and DC supply connections Fulfilled Fulfilled
EN 55032 Telecommunication connections Class A Class A
EN 61000-6-4 Telecommunication connections Fulfilled Fulfilled
