Hirschmann RSP 25 User Manual

Installation RSP 20/25/30/35 Release
15
12/2017
55
EMC interference immunity Standard applications Substation applications
Electrostatic discharge
EN 61000-4-2
IEEE C37.90.3
Contact discharge ±4 kV ±8 kV
EN 61000-4-2
IEEE C37.90.3
Air discharge ±8 kV ± 15 kV
Electromagnetic field
EN 61000-4-3 80 MHz ... 3000 MHz 10 V/m 10 V/m
IEEE 1613 80 MHz ... 1000 MHz — 35 V/m
Fast transients (burst)
EN 61000-4-4
IEEE C37.90.1
AC/DC supply connection ±2 kV ±4 kV
EN 61000-4-4
IEEE C37.90.1
Data line ±4 kV ±4 kV
Voltage surges - DC supply connection
EN 61000-4-5 line/ground ±2 kV ±2 kV
IEEE 1613 line/ground — ± 5 kV
EN 61000-4-5 line/line ±1 kV ±1 kV
Voltage surges - AC supply connection
EN 61000-4-5 line/ground ±2 kV ±4 kV
IEEE 1613 line/ground — ± 5 kV
EN 61000-4-5 line/line ±1 kV ±2 kV
Voltage surges - data line
EN 61000-4-5 line/ground ±1 kV ±4 kV
Conducted disturbances
EN 61000-4-6 150 kHz ... 80 MHz 10 V 10 V
Damped oscillation - AC/DC supply connection
EN 61000-4-12
IEEE C37.90.1
line/ground — 2.5 kV
EN 61000-4-12
IEEE C37.90.1
line/line — 1 kV
