Installation RSP 20/25/30/35
Release
15
12/2017
19
The Hirschmann network components help you ensure continuous
communication across all levels of the company.
1.2 Device name and product code
The device name corresponds to the product code. The product code is
made up of characteristics with defined positions. The characteristic values
stand for specific product properties.
You have numerous options of combining the device characteristics. You can
determine the possible combinations using the Configurator which is
available in the Belden E-Catalog (www.e-catalog.beldensolutions.com) on
the web page of the device.
Item Characteristic Character
istic value
Description
1 ... 5 Product RSP20 Fast Ethernet switch
RSP25 Fast Ethernet switch with extended redundancy
function
RSP30 Gigabit Ethernet switch
RSP35 Gigabit Ethernet switch with extended
redundancy function
6 (hyphen) –
7 ... 8 Number
Fast Ethernet ports
08 8 ×
11 11 ×
9 ... 10 Number
Gigabit Ethernet ports
00 0 ×
03 3 ×
11 ... 13 Configuration of the
uplink ports
3Z6 3 × Optional SFP slot for:
100 Mbit/s twisted pair connections
100 Mbit/s F/O connections
3O6 3 × Optional SFP slot for:
100 Mbit/s twisted pair connections
1000 Mbit/s twisted pair connections
100 Mbit/s F/O connections
1000 Mbit/s F/O connections
14 ... 15 Configuration of the
other ports
TT 8 × RJ45 socket for 10/100 Mbit/s twisted pair
connections
ZT 4 × RJ45 socket for 10/100 Mbit/s twisted pair
connections
4 × Optional SFP slot for:
100 Mbit/s twisted pair connections
100 Mbit/s F/O connections
16 (hyphen) –
Table 4: Device name and product code
