36
Installation RSP 20/25/30/35
Release
15
12/2017
Ground the device via the ground screw.
For the supply voltage to be connected, perform the following steps:
Remove the power connector from the device.
Connect the protective conductor according to the pin assignment on the
device with the clamp.
Connect the wires according to the pin assignment on the device with the
clamps.
Fasten the wires connected by tightening the terminal screws.
AC voltage Rated voltage range AC
110 V AC ... 230 V AC,
50 Hz ... 60 Hz
Voltage range AC including
maximum tolerances
88 V AC ... 265 V AC,
47 Hz ... 63 Hz
+/L Outer conductor
−/N Neutral conductor
Protective conductor
WARNING
ELECTRIC SHOCK
Install this device solely in a switch cabinet or in an operating site with
restricted access, to which maintenance staff have exclusive access.
Failure to follow this instruction can result in death, serious injury, or
equipment damage.
Type of the voltages
that can be
connected
Specification of the supply
voltage
Pin assignment
Table 6: Supply voltage with characteristic value K9: type and specification of the
supply voltage, pin assignment
