Installation RSP 20/25/30/35
Release
15
12/2017
51
Climatic
conditions during
storage
Ambient air temperature
b
−40 °F ... +185 °F (−40 °C ... +85 °C)
Humidity 5 % ... 95 %
(non-condensing)
Air pressure min. 700 hPa (+9842 ft; +3000 m)
max. 1060 hPa (−1312 ft; −400 m)
Signal contact
(only for device variants featuring supply voltage with characteristic value CC and TT)
Connection type 2-pin terminal block
Tightening torque 3 lb-in (0.34 Nm)
Nominal value for AC I
max
=1A at U
max
=30VAC
Nominal value for DC I
max
=1A at U
max
=60VDC
according to the UL Standards:
Nominal value for AC I
max
=1A at U
max
=30VAC
Nominal value for DC I
max
=1A at U
max
=30VDC
according to the Standards ANSI/ISA 12.12.01-2011:
See Control Drawing in chapter “Relevant for use in explosion hazard areas
(Hazardous Locations, Class I, Division 2):” on page 10.
Signal contact
(only for device variants featuring supply voltage with characteristic value K9 and KK)
Connection type 2-pin terminal block
Tightening torque 3 lb-in (0.34 Nm)
Nominal value for AC I
max
=1A at U
max
=230VAC
Nominal value for DC I
max
=1A at U
max
=60VDC
I
max
= 0.2 A at U
max
= 125 V DC
I
max
= 0.1 A at U
max
= 250 V DC
according to the UL Standards:
Nominal value for AC I
max
=1A at U
max
=30VAC
Nominal value for DC I
max
=1A at U
max
=30VDC
according to the Standards ANSI/ISA 12.12.01-2011:
See Control Drawing in chapter “Relevant for use in explosion hazard areas
(Hazardous Locations, Class I, Division 2):” on page 10.
Pollution degree 2
Protection classes Laser protection Class 1 in compliance with IEC 60825-1
Degree of protection IP20
a. Reduction of the maximum permitted ambient air temperature under specific conditions
b. Temperature of the ambient air at a distance of 2 in (5 cm) from the device
c. Hirschmann recommends to use SFP transceivers with “EEC” extension.
d. Use SFP transceivers with the “EEC” extension only, otherwise the standard temperature
range applies.
e. When using supply voltage with characteristic value CC, K9 or KK:
- applies when device is equipped with max. 4 SFP transceivers
- if a higher number is connected, the following maximum values apply for the ambient air
temperature: 5 transceivers: +154 °F (+68 °C); 6 transceivers: +149 °F (+67 °C);
7 transceivers: +140 °F (+65 °C)
When using supply voltage with characteristic value TT:
- applies when device is equipped with max. 2 SFP transceivers
- if a higher number is connected, the following maximum values apply for the ambient air
temperature: 4 transceivers: +140 °F (+65 °C); 5 to 7 transceivers: +140 °F (+60 °C)
f. When using supply voltage with characteristic value CC, K9 or KK:
- applies when device is equipped with max. 4 SFP transceivers
- if a higher number is connected, the following maximum values apply for the ambient air
temperature: 5 to 7 transceivers: +176 °F (+80 °C)
When using supply voltage with characteristic value TT:
- applies when device is equipped with max. 2 SFP transceivers
- if a higher number is connected, the following maximum values apply for the ambient air
temperature: 4 transceivers: +176 °F (+80 °C); 5 to 7 transceivers: +167 °F (+75 °C)
