Hirschmann RSP 25 User Manual

58
Installation RSP 20/25/30/35
Release
15
12/2017
a. MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul
b. Including 3 dB system reserve when compliance with the fiber data is observed.
c. Using the bandwidth-length product is inappropriate for expansion calculations.
d. With F/O adapter compliant with IEEE 802.3-2002 Clause 38 (single-mode fiber offset-launch mode conditioning patch cord).
e. With F/O adapter compliant with IEEE 802.3-2002 Clause 38 (single-mode fiber offset-launch mode conditioning patch cord).
f. Including 2.5 dB system reserve when compliance with the fiber data is observed.
Product code
M-SFP-BIDI...
Mode
a
a. MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul
Wave length
TX
Wave length
RX
Fiber System
attenuation
Example for
F/O cable
length
b
b. Including 3 dB system reserve when compliance with the fiber data is observed.
Fiber
attenuation
Dispersion
Type A LX/LC
EEC
SM 1310 nm 1550 nm 9/125 µm 0 dB ... 11 dB 0 km ...
12.43 mi
(0 km ...
20 km)
0.4 dB/km 3.5 ps/(nm×km)
Type B LX/LC
EEC
SM 1550 nm 1310 nm 9/125 µm 0 dB ... 11 dB 0 mi ...
12.43 mi
(0 km ...
20 km)
0.25 dB/km 19 ps/(nm×km)
Type A LH/LC
EEC
LH 1490 nm 1590 nm 9/125 µm 5 dB ... 24 dB 14.29 mi ...
49.71 mi
(23 km ...
80 km)
0.25 dB/km 19 ps/(nm×km)
Type B LH/LC
EEC
LH 1590 nm 1490 nm 9/125 µm 5 dB ... 24 dB 14.29 mi ...
49.71 mi
(23 km ...
80 km)
0.25 dB/km 19 ps/(nm×km)
Table 12: F/O port (bidirectional Gigabit Ethernet SFP Transceiver)
