Hisense I6433C7 User Manual

First, feed the power cord through the cutout. Place the appliance over the centre of the cutout.
Connect the appliance to the power mains (see instructions for connecting the appliance). Before
sealing the appliance, test its operation. Seal the slot between the appliance and the countertop using
a silicone sealant. The silicone sealant used to seal the appliance has to be temperature-resistant (to
at least 160 °C). Smooth out the silicone sealant using a suitable tool. Observe the instructions for
use of the selected silicone sealant. Do not switch on the appliance until the silicone sealant has dried
completely.
1. Silicone sealant
2. Sealing tape
WARNING!
Pay particular attention to built-in dimensions with (natural) stone countertops. When choosing
the silicone sealant, observe the countertop material and consult the countertop manufacturer.
Use of inappropriate silicone sealants can result in permanent discolouration of some parts.
Removing the built-in appliance
Disconnect the appliance from the powermains. Use a suitable tool to remove the silicone gasket from
the perimeter. Remove the appliance by pushing it upwards from the bottom side.
WARNING!
Do not attempt to remove the appliance from the upper side of countertop.
WARNING!
The service department shall only be responsible for repair and servicing of the cooking hob.
Consult your specialized kitchen equipment dealer regarding the re-installation (of the flush-mount)
cooking hob.
Stone countertop
1. Countertop
2. Appliance
3. Slot
29

Hisense I6433C7 Specifications

General

Hob type	Zone induction hob
Frame type	Frameless
Finish type	Gloss
Warming zone	Yes
Product color	Black
Hob width size	59.5 cm
Top surface type	Glass-ceramic
Appliance placement	Built-in
Cooking zone 1 type	Regular
Cooking zone 3 type	Large
Cooking zone 4 type	Simmer
Cooking zone 1 boost	2000 W
Cooking zone 1 power	1500 W
Cooking zone 1 shape	Round
Cooking zone 4 boost	1600 W
Cooking zone 4 power	1200 W
Warming zone position	-
Cooking zone 1 diameter	180 mm
Cooking zone 1 position	Left front
Cooking zone 2 position	Left rear
Cooking zone 3 diameter	210 mm
Cooking zone 3 position	Right rear
Cooking zone 4 diameter	145 mm
Cooking zone 4 position	Right front
Number of cooking zones	4 zone(s)
Number of warming zones	4
Cooking zone 1 power source	Gas
Cooking zone 2 power source	Electric
Number of gas cooking zones	0 zone(s)
Stop & Go function	No
Country of origin	Slovenia
Clock type	Electronic
Timer type	Digital
Control type	Touch
Display type	LED
Control position	Front
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Connected load (gas)	0 W
Connected load (electric)	7200 W
Package depth	575 mm
Package width	640 mm
Package height	160 mm
Package weight	8100 g

Weight and Dimensions

Depth	520 mm
Width	595 mm
Height	58 mm
Weight	7600 g
Cord length	0 m
Installation compartment depth	490 mm
Installation compartment width	560 mm
Installation compartment height	74 mm
