--- 8 ---
Fig. 10
107 x 107
(4-3/16" x 4-3/16")
Maker
Model
Max.
cutting
dimensions
HITACHI
C 12LSH
C 12RSH
Height x Width
(H x W)
Table 5
Unit: mm (inch)
C
98 x 134
(3-7/8" x 5-1/4")
107 x 122
(4-1/4" x 4-13/16")
[with aux. board width
34 mm (1-5/16")]
P
102 x 102
(4" x 4")
115 x 115
(4-1/2" x 4-1/2")
(11) Press cutting
Press cutting with the head swiveling enables cutting workpieces
as large as shown in Table 5 in a single sawing operation. It is
convenient for cutting narrow workpieces (Fig. 10).
100 x 100
(4" x 4")
HITACHI
C 12FSA
Table 6
Unit: mm (inch)
Maker
Model
Max.
cutting
dimensions
HITACHI
C 12LSH
C 12RSH
Right and left 45û
Height x Width
(H x W)
Right 57û (Hitachi
C 12LSH, C 12RSH)
Right and left 57û
(Hitachi C 12FSA)
Right 60û (C)
Height x Width
(H x W)
107 x 220
(4-3/16" x 8-5/8")
120 x 180
(4-11/16" x 7-1/16")
with aux. board width
25 mm (1")
107 x 170
(4-3/16" x 6-11/16")
120 x 130
(4-11/16" x 5-1/8")
with aux. board width
25 mm (1")
HITACHI
C 12FSA
107 x 220
(4-3/16" x 8-5/8")
120 x 180
(4-11/16" x 7-1/16")
with aux. board width
25 mm (1")
C
98 x 220
(3-7/8" x 8-5/8")
120 x 162
(4-11/16" x 6-3/8")
[with aux. board width
24 mm (15/16")]
(12) Miter cutting
* These numeric values are for the models destined for the U.S.A. and Canada.
Refer to "5. SPECIFICATIONS" as the capacities are different depending on the destinations.
P
102 x 216
(4" x 8-1/2")
115 x 203
(4-1/2" x 8")
107 x 180
(4-3/16" x 7-1/16")
120 x 140
(4-11/16" x 5-1/2")
with aux. board width
25 mm (1")
98 x 155
(3-7/8" x 6-1/8")
120 x 115
(4-11/16" x 4-1/2")
with aux. board width
17 mm (11/16")
Fig. 11
Workpieces as wide as shown in Table 6 can be cut by
swiveling the turn table (right and left).
The maximum cutting dimensions in [ ] in Table 6 are those
obtained by adjusting the lower limit position of the saw blade
indicated in Fig. 9-b, also with an auxiliary board.
