--- 9 ---
(13) Right and left bevel cutting
* These numeric values are for the models destined for the U.S.A. and Canada.
Refer to "5. SPECIFICATIONS" as the capacities are different depending on the destinations.
Maximum cutting dimension
Unit: mm (inch)
Maker
Model
Max.
cutting
dimensions
HITACHI
C 12LSH
C 12RSH
Left 45û
Height x Width
(H x W)
Right 45û
Height x Width
(H x W)
70 x 312
(2-3/4" x 12-1/4")
75 x 260
(2-15/16" x 10-3/16")
with aux. board width
25 mm (1")
45 x 312
(1-3/4" x 12-1/4")
50 x 260
(1-15/16" x 10-3/16")
with aux. board width
25 mm (1")
HITACHI
C 12FSA
70 x 305
(2-3/4" x 12")
75 x 260
(2-15/16" x 10-3/16")
with aux. board width
20 mm (13/16")
C
55 x 310
(2-3/16" x 12-1/4")
69 x 230
(2-3/4" x 9")
[with aux. board
34 mm (1-5/16")]
Workpieces as wide as shown in Table 7 can be bevel-cut by tilting the saw blade (right and left).
P
57 x 305
(2-1/4" x 12")
79 x 200
(3-1/8" x 7-7/8")
40 x 305
(1-9/16" x 12")
45 x 260
(1-3/4" x 10-3/16")
with aux. board width
20 mm (13/16")
35 x 310
(1-3/8" x 12-1/4")
49 x 230
(1-15/16" x 9")
[with aux. board width
34 mm (1-5/16")]
28 x 305
(1-1/8" x 12")
41 x 270
(1-5/8" x 10-5/8")
Table 7
1
Fig. 12 Fig. 13
Fig. 14
Fig. 15
Bevel cutting
2
