--- 30 ---
(1) Setting to cut crown moldings at positions and in Fig. 39 (See Fig. 40, tilt the head to the left.):
Turn the turn table to the right and set the miter angle as follows:
For 45û type crown moldings: 35.3û
For 38û type crown moldings: 31.6û
Turn the head to the left and set the bevel angle as follows:
For 45û type crown moldings: 30û
For 38û type crown moldings: 33.9û
Position the crown molding so that the lower surface ( in Fig. 38) contacts the fence as indicated in
Fig. 42.
Type of
crown molding
To process crown molding at
positions and in Fig. 39
To process crown molding at
positions and in Fig. 39
Miter angle
setting
Bevel angle
setting
Miter angle
setting
Bevel angle
setting
Right 30ûRight 35.3û Left 30û Right 30û Left 35.3û Left 30û
For miter cut setting
If the turn table has been set to either of the angles described, move the turn table adjusting side handle a little
to the right and left to stabilize the position and to properly align the miter scale and the tip of the indicator
before the operation starts. Then tighten the side handle.
For bevel cut setting
Turn the clamp lever on bevel section to the right and left and check that the position is stable and the angle
scale and the tip of the indicator are properly aligned. Then tighten the clamp lever.
45û type
Right 31.6û Left 33.9û Right 33.9û Left 31.6û Left 33.9û
38û type
3
1 4
2
Right 33.9û
Table 10
1
4
2
3 A
1
(2) Setting to cut crown moldings at positions and in Fig. 39 (See Fig. 41, tilt the head to the left.):
Turn the turn table to the left and set the miter angle as follows:
For 45û type crown moldings: 35.3û
For 38û type crown moldings: 31.6û
Tilt the head to the left and set the bevel angle as follows:
For 45û type crown moldings: 30û
For 38û type crown moldings: 33.9û
Position the crown molding so that the lower surface ( in Fig. 38) contacts the fence as indicated in
Fig. 43.
2 3
1
2
3
B
