--- 33 ---
To ensure that the tip of the 6 mm wing bolt is properly aligned with the desired locking groove on the vise
shaft, simply align the upper surface of the fence to either of three v-grooves on the vise shaft surface or to the
lower surface of the screw holder. Therefore, the vise assembly can be attached in either of three positions to
ensure proper height.
WARNING: Always firmly clamp or vise to secure the crown molding to the fence; otherwise the
crown molding might be thrust from the table and cause bodily harm. Do not perform
bevel cutting. The main body or saw blade may contact the sub fence, resulting in an
injury.
CAUTION: Always confirm that the motor head does not contact the crown molding vise ass'y
when it is lowered for cutting. If there is any danger that it may do so, loosen the 6 mm
knob bolt and move the crown molding vise ass'y to a position where it will not contact
the saw blade.
For inside corner
For outside corner
Position in Fig. 36
Miter angle
Finished piece
Save the right side of blade.
Save the left side of blade.
Save the right side of blade.
Save the left side of blade.
2
1
3
4
Right 45û
Left 45û
Right 45û
Table 11
Position crown molding with its WALL CONTACT EDGE against the guide fence and its CEILING CONTACT
EDGE against the crown molding stoppers as shown in Fig. 48-b. Adjust the crown molding stoppers
according to the size of the crown molding. Tighten the 6 mm wing bolt to secure the crown molding stoppers.
Refer to Table 11 below for the miter angle.
To Next Page
