Tree configuration Description
module, and operates the switch
module.
Sets basic configuration of Hitachi
1 Gb LAN switch module (20-port,
40-port) and Hitachi 1 Gb/10 Gb
LAN switch module; starts the
Web console window of Brocade 8
Gb fibre channel switch module
and 16 Gb fibre channel switch
module.
Management Modules
5
Management
Module 0 – 1
Shows the operation status and
hardware information of a
specified management module,
and operates the management
module.
Fan Modules Shows the operation status of fan
modules.
Power Supply Modules
6
Power Supply
Module 0 – 3
Shows the operation state and
hardware information of a
specified power supply module.
Systems
7
Network management
8
Management
LAN
Controls the management LAN
interface of server blades (BMC),
switch modules, management
modules.
Setting an IP address, subnet
mask, gateway, and DNS is
available. You can also set up IPv6
addresses, prefixes, gateways,
and DNS servers.
Maintenance
LAN
Shows the maintenance LAN
interface of a management
module; cannot change settings.
Internal LAN Sets a network used inside the
system unit.
Link Fault
Tolerance
Enables/disables the link fault
tolerance, and sets time for
monitoring.
WWN management Shows and sets WWN, including
the Default Physical WWN unique
to hardware, an Optional Physical
WWN, and virtual WWN, used by a
mezzanine card installed in a
server blade.
MAC management Shows and sets the MAC address,
including the Default Physical MAC
address unique to hardware, an
Optional Physical MAC address,
and virtual MAC address, used by
a mezzanine card installed in a
server blade.
Operating the Web Console
2-7
