E-Compact Medium Power
6.2.2. Specifications
Characteristic
Specification
PA702MP
PA704MP
Input
Frequency
Range
470 to 806 MHz
See PA702MP / PA704MP Channel Range Table
Level
0.0 to 8.0 dBm (±1dB)
Connector /
Impedance
SMA female / 50 Ohms
Return Loss
-20dB typical ( -18dB Max )
Output
Frequency
Range
470 to 806 MHz
Output Power
215 Wrms (ATSC 3.0)
225 Wrms (ATSC 1.0)
400 Wrms (ATSC 3.0)
450 Wrms (ATSC 1.0)
RF Sample
470 to 806 MHz / +10dBm
Connector /
Impedance
DIN 7/16” female – 50 Ω
Return Loss
-20dB typical ( -18dB Max ) - measured with the drawer off
Harmonics /
Spurious
-30dBc
Average MER
Better than 33dB:
Pout = 215Wrms@ ATSC 3.0
Better than 36dB:
Pout= 225Wrms @ATSC 1.0
Better than 33dB:
Pout = 400Wrms@ ATSC 3.0
Better than 36dB:
Pout= 450Wrms @ATSC 1.0
General
Communication
Interface
USB / RS-485
AC Mains
100Vac to 254VAC / 43 to 63Hz
180Vac to 254VAC / 43 to 63Hz
Power Factor
> 0.92
Gain
52dB (± 4.0dB)
Average
Efficiency
32% typical @ ATSC 3.0 Pout: 215W
32% typical @ ATSC 3.0 Pout: 400W
