Chapter 2 Specifications
2 – 27
(10) EH-XD32H
Item PIM-DM, PIH-DM (for replacing)
EH-XD32H (This product)
Series
EM/EM-
Ⅱ, H-200/250/252
EH-150
Input specification DC source input
Number of inputs 32
Input voltage 24 V DC (21.6 to 26.0 V DC)
Input current (24V DC) Approx. 4.7 mA Approx. 4.1 mA
Input impedance
Approx. 5.1 k
Ω Approx. 5.9 kΩ
Operating ON voltage 19 V minimum
voltage OFF voltage 7 V maximum
Input response OFFÎON 4 ms maximum
time ON ÎOFF 4 ms maximum
Insulation method Photo-coupler insulation
Number of inputs / common 32 (1 common, 4 terminals)
Input display LED (red) LED (green)
Polarity Common terminal (+)
External connection Connector (50 pins)
Internal current consumption 20 mA maximum 60 mA maximum
Specification of external wiring connector
Product name Manufacturer Product No. Connection method
Wire
DX30-50P AWG#30
DX30A-50P
Untie crimping
AWG#28
DX31-50P AWG#30
DX31A-50P
Crimping
AWG#28
Plug connector
DX40-50P Soldering
－
Die cast cover
Hirose Electric Co., Ltd.
DX-50-CV1
－ －
To Next Page
