Hitachi RPI-5.0FSN4E Service Manual

6 Optional functions
225
6
SMGB0077 rev.0 - 01/2013
Element Optional function
Individual
setting
Settings Condition setting Description
bb
Cooling temperature
compensation
X
00
Standard setting.
No compensation
This function is used to obtain longer
cooling periods.
01
It decrease the
temperature -1ºC
02
It decrease the
temperature -2ºC
bC
Not available –
00
Not available
Use at 00 conditions
–
01 –
bd
Not available –
00
Not available
Use at 00 conditions
–
01 –
bE
Not available –
00
Not available
Use at 00 conditions
–
01 –
C1
Not available –
00
Not available
Use at 00 conditions
–
01 –
C2
Not available –
“- -”
permanent
Not available –
C3
HA function (only for Japanese
market)
O
00
Not available
Use at 00 conditions
–
01 –
C4
Drain pump in heating mode O
00
Not activated
function
This function is used to activate the
drain pump in heating mode.
01 Activated function
C5
Static pressure selection (RPI)
O
00
Standard static
pressure (factory
set)
This function is used to increase the
fan speed on the indoor ducted units.
01 High static pressure
02 Low static pressure
Increasing fan speed (RCI,
RCIM, RCD)
00 Not available
This function is used to change the
indoor units fan speed installed in high
ceilings.
01 Hi Speed 1
(2)
02 Hi Speed 2
(2)
C6
PC-ART: increasing fan speed
PC-ARF: Hi speed at heating
Thermo-OFF
O
00
Not activated
function
PC-ARF: This function is used
to increase the fan speed when
the thermostat reaches the set
temperature in heating using function
C5.
01 Activated function
C7
Cancellation of the forced
compressor operation for at
least three minutes
O
00 Activated function
Cancels function b3.
01
Not activated
function
