Number Part name Remarks
1 Terminal Board -
2 Remote Control SW PC-ART (Optional)
3 Electrical Box Assembly (Components + Harness)
3 Electrical Box Assembly (Components + Harness)
3 Electrical Box Assembly (Components + Harness)
3 Electrical Box Assembly (Components + Harness)
3 Electrical Box Assembly (Components + Harness)
3 Electrical Box Assembly (Components + Harness)
4 Capacitor Assy. -
5 Thermistor For liquid Pipe
6 Thermistor For Gas Pipe
7 Thermistor For Inlet Air
8 Thermistor For Outlet Air
9 Expansion Valve -
9 Expansion Valve -
9 Expansion Valve -
10 Expansion Valve Coil -
11 Filter -
11 Filter -
12 Fan Casing/Runner Fan Casing + Runner
13 Heat Exchanger Assembly
13 Heat Exchanger Assembly
13 Heat Exchanger Assembly
13 Heat Exchanger Assembly
14 Spacer For PCB Fixing
15 Push Spacer For PCB Fixing
16 Drain Pump Discharge Mechanism
17 Fan Motor -
17 Fan Motor -
17 Fan Motor -
18 Fan Assy Assembly (Motor+Stay+Runners+Casing)
18 Fan Assy Assembly (Motor+Stay+Runners+Casing)
18 Fan Assy Assembly (Motor+Stay+Runners+Casing)
19 PCB1 Control PCB
20 PCB2 Power PCB
20 PCB2 Power PCB
20 PCB2 Power PCB
21 Float Switch -
22 Drain Pan Assembly
22 Drain Pan Assembly
