10 Servicing
388
SMGB0077 rev.0 - 01/2013
5 Remove the lower horizontal louver in the same procedure as the upper horizontal louver.
6 When mounting the horizontal louvers, mount the louvers in the reverse procedure.
N O T E
When mounting the horizontal louvers, insert the D-cut portions at the far right shafts of the louvers into the AS Motor
shafts.
