Hitachi RPI-5.0FSN4E Service Manual

2 Unit installation
SMGB0077 rev.0 - 01/2013
35
2
S
Electrical connection of the air panel
C A U T I O N
Switch off the power supply to the unit before coupling the connectors, otherwise the automatic louver will not
work.
The following connector is used with the air panel (see from the lower surface of the air panel without the air inlet grille).
Connect the connectors for auto-swing motor (Low voltage 5pin, white).
Connector for auto swing motor
(Air panel side)
Connector for auto swing motor
(Indoor unit side)
Without air inlet grille
Electrical box
