35
PMEN0654 rev.0 - 12/2023
7
SETTING OF DIP SWITCHES FOR OUTDOOR UNIT
DIP SWITCHES
   DSW3: Capacity Seng (No seng is required)
DSW3
Model RAS-2HVRC3
Factory seng
Model RAS-2.5HVRC3
Factory seng
Model RAS-3HVRC3
Factory seng
   DSW4 / RSW1: Refrigerant cycle number seng (Seng is required)
DSW4
Factory seng
Seng for the tens digit
RSW1
Factory seng
Set by inserng sloed screwdriver into the
groove (seng for the last digit)
   DSW5: End terminal resistance
DSW5
Factory seng
