Hitachi UTOPIA R32 Series User Manual

74
PMEN0654 rev.0 - 12/2023
16
SNOWPROTECTIONHOOD
OPTIONAL PARTS FOR RAS-(2-3)HVRC3 SERIES
16.4.4 Assembly of snow protecon hood
A B C
1
3
1
2
4
6
1
5
3
a
7
A
B
C
1
3
1
2
4
6
1
5
3
a
7
A. Rear side
B. Le side
C. Front side
1. Fixing screw
2. Air inlet hood
3. Wire rope (oponal for over turning protecon)
4. Air discharge hood
5. Outdoor unit
6. Le sucon hood
7. Air discharge grille
 NOTE
• a > Maximum snowfall height.
• Base structure supplied in the eld.
