Hitachi UTOPIA R32 Series - 16.3 Wind Guard

70
PMEN0654 rev.0 - 12/2023
16
WINDGUARD
OPTIONAL PARTS FOR RAS-(2-3)HVRC3 SERIES
16.3 Wind guard
16.3.1 WSP-SP10A
◆ Specicaons
Material Galvanized sheet metal + baked painng
1
1
2
2
Color UTOPIA Beige (Munsell code: 2.5Y8/2)
Weight 4.0 kg
Accessories
Unit xing screw 4 x [M5 (SUS) x 30]
Wind guard
xing screw
10 x [M5 (SUS) x 12]
Installaon manual
Installaon restricon
“Guard net” “Air ow guide” or “Snow
protecon hood” is not available to
install with Wind guard
4-6x10 Long Hole
5 (Both Sides) - M5 Screw (aachment)
◆ One wind guard cover installaon
202
Wind guard
Air discharge grille
4 x M5 xing screw
(Accessories)
◆ Service space (In case of upward air discharge)
• In case of right and le sides air discharge enough space
for air discharge is required.
• The downward air discharge is also available. In such
case install the base under the unit to secure enough
space for air discharge.
• In case of serial units installaon air discharge should be
upward.
Min. 150 mm
