Hitachi UTOPIA R32 Series - 16.1 Assigned Models and Quantity; 16.2 Air Flow Guide

68
PMEN0654 rev.0 - 12/2023
16
ASSIGNEDMODELSANDQUANTITY
OPTIONAL PARTS FOR RAS-(2-3)HVRC3 SERIES
16.1 Assigned models and quanty
RAS-(2-3)HVRC3
Air ow guide
AG-264
1
Wind guard
WSP-SP10A
1
Snow protecon hood (Zinc plate)
ASG-SP10FTB (Half)
Air outlet
1
ASG-SP11FTB (Full) 1
ASG-SP10BTB
Air inlet of rear side
1
ASG-SP10LTB Air inlet of side face 1
16.2 Air ow guide
16.2.1 AG-264
◆ Specicaons
Air discharge direcon Upward (downward) le and right
18
Material Weather proof polypropylene resin
Color Gray (Munsell code: 1.0Y8.5/0.5)
Weight 1.7 kg
Accessories
Fixing screw 4 x [M5 (SUS) x 12] + 4 x [M5 (SUS) x 30]
Self-screw Self-screw 2x [M4 x 13]
Installaon manual
Installaon restricon
“Wind Guard” or “Snow protecon hood”
is not available to install with air ow
guide. (“Guard net” is available to be
installed together.)
