Hitachi WL200 Series - Page 58

56
“A” Function
A
B
Defaults
Func.
Code
Name
Description
Initial data
Units

Deceleration time (2)
Duration of 2
nd
segment of
deceleration, range is:
0.00 to 3600 sec.


10.00
s

Deceleration time (2),
2
nd
motor


10.00
s

Select method to switch
to Acc2/Dec2 profile
Three options for switching
from 1st to 2nd accel/decel:
2CH input from terminal
Transition frequency
Forward and reverse


00


Select method to switch
to Acc2/Dec2 profile, 2
nd
motor


00


Acc1 to Acc2 frequency
transition point
Output frequency at which
Accel1 switches to Accel2,
range is 0.00 to 400.0 Hz


0.0
Hz

Acc1 to Acc2 frequency
transition point,
2
nd
motor


0.0
Hz

Dec1 to Dec2 frequency
transition point
Output frequency at which
Decel1 switches to Decel2,
range is 0.00 to 400.0 Hz


0.0
Hz

Dec1 to Dec2 frequency
transition point,
2
nd
motor


0.0
Hz

Acceleration curve
selection
Set the characteristic curve of
Acc1 and Acc2, five options:
linear
S-curve
U-curve
Inverse U-curve


01


Deceleration curve
selection
Set the characteristic curve of
Dec1 and Dec2, options are
same as above ()


01


[OI] input active range
start frequency
The output frequency
corresponding to the analog
input range starting point,
range is 0.00 to 400.0 Hz


0.00
Hz

[OI] input active range
end frequency
The output frequency
corresponding to the current
input range ending point,
range is 0.00 to 400.0 Hz


0.00
Hz

[OI] input active range
start current
The starting point (offset) for
the current input range,
range is 0. to 100.%


20.
%

[OI] input active range
end current
The ending point (offset) for
the current input range,
range is 0. to 100.%


100.
%

[OI] input start
frequency select
Two options; select codes:
Use offset ( value)
Use 0Hz


00


Acceleration curve
constant
Range is 01 to 10.


2


Deceleration curve
constant
Range is 01 to 10.


2

