- 15 -
Func.
Code
Name / Description
Default
-FE/-FU
Set
value
A296
A097 Acceleration curve selection
y 00 Linear y 01 S-curve
00
A098 Deceleration curve selection
y 00 Linear y 01 S-curve
00
A101 [OI]-[L] input active range start frequency 0.0
A102 [OI]-[L] input active range end frequency 0.0
A103 [OI]-[L] input active range start current 0.
A104 [OI]-[L] input active range end current 100.
A105 [OI]-[L] input start frequency enable
y 00 Use A101 (starting value)
y 01 Use 0Hz
01
A141 Input A select for calculate function
y 00 Integrated operator
y 01 Keypad POT
y 02 [O] input
y 03 [OI] input
y 04 Network variable
01
A142 Input A select for calculate function
y 00 Integrated operator
y 01 Keypad POT
y 02 [O] input
y 03 [OI] input
y 04 Network variable
02
A143 Calculation symbol
y 00 ADD (A + B)
y 01 SUB (A - B)
y 02 MUL (A * B)
00
A145 ADD frequency 0.0
A146 ADD direction select
y 00 Plus (adds A145 value to output freq.)
y 01 Minus (subtracts A145 value from output freq.)
00
A151 POT active range start frequency 0.0
A152 POT input active range end frequency 0.0
A153 POT input active range start 0.
A154 POT input active range end 100.
A155 POT input start frequency enable 01
