18
Warning and Error Messages
Indicates each cell’s resistance.
The display indicates the total resistance.
Press the START/ENTER button to access
the Lithium Battery Meter program.
Battery Resistance Meter
The user can check the battery’s total resistance.
Please connect the balance wire attached to the battery to the balance socket and the XT60
male connector to the XT60 female connector in front of the charger.
BATT/PROGRAM
BATT RESISTANCE
6.7 12.8mΩ
0.0 0.0mΩ
TOTAL: 19.5mΩ
IN C
START
ENTER
(-)
(-)
(Negative wire is black)
BATTERY CHECK
.......
