20
System Setting
ITEM SELECTION DESCRIPTION
When powered on for the rst time, your RDX2 Mini charger will load with default values in the
programmable user settings. The screen displays the following information in sequence and the
user can change the value of the parameters on each screen.
When you are ready to change the parameter values in the program, press START/ENTER
to make it blink, and then select the appropriate values with INC or DEC. Store the value by
pressing START/ENTER once.
Safety Timer
ON 120Min
Capacity Cut-Off
ON 5000mAh
When you start a charge process, the
integral safety timer automatically starts
running at the same time. It is programmed
to prevent overcharging of the battery if
it proves to be faulty, or termination circuit
cannot be determined if battery is full. The
value for the safety should be generous
enough to allow charging of the battery.
This program sets the maximum capacity
that will be supplied during the battery
charge. If the delta voltage is not detected,
or if the timer expires for any reason, this will
automatically stop the charge process upon
reaching the selected value.
OFF/ON
(100-50000mAh)
Cut-o : 5000mAh
OFF/ON
1-720 Min
To Next Page
