Hitron CGN3 User’s Guide
IP Address This displays the CGN3’s WAN IP address. This IP
address is automatically assigned to the CGN3
Subnet Mask This displays the CGN3’s WAN subnet mask.
Gateway IP This displays the IP address of the device to which the
CGN3 is connected over the CABLE interface.
DHCP Lease Time This displays the time that elapses before your device’s
IP address lease expires, and a new IP address is
assigned to it by the DHCP server.
Downstream Overview
NOTE: The downstream signal is the signal transmitted to the CGN3.
Port ID This displays the ID number of the downstream
connection’s port.
Frequency (MHz) This displays the actual frequency in Megahertz (MHz)
of each downstream data channel to which the CGN3 is
connected.
Modulation This displays the type of modulation that each
downstream channel uses.
Signal Strength
(dBmV)
This displays the power of the signal of each
downstream data channel to which the CGN3 is
connected, in dBmV (decibels above/below 1 millivolt).
Signal Noise Ratio
(dB)
This displays the Signal to Noise Ratio (SNR) of each
downstream data channel to which the CGN3 is
connected, in dB (decibels).
Channel ID This displays the ID number of each channel on which
the downstream signal is transmitted.
Upstream Overview
NOTE: The upstream signal is the signal transmitted from the CGN3.
Port ID This displays the ID number of the upstream
connection’s port.
Frequency (MHz) This displays the actual frequency in Megahertz (MHz)
of each upstream data channel to which the CGN3 is
connected.
Modulation This displays the type of modulation that each upstream
channel uses.
Table 12: The Status: DOCSIS WAN Screen (continued)
