1. General information
1.1 About these assembly instructions
These assembly instructions are intended for planners, developers and operators of systems who plan for and install linear
guideways as machine elements. They are also intended for persons who perform the following tasks:
| Transportation
| Assembly
| Retrofitting or upgrading
| Setup
| Commissioning
| Operation
| Cleaning
| Maintenance
| Troubleshooting and error elimination
| Shutdown, disassembly and disposal
Version Date Notes
04-0 October 2019 Complete revision of document
03-1 September 2018 Update
03-0 July 2017 Complete revision of document; addition of CG and QW series; taking out of MG-O series
02-5 January 2017 Update
02-4 May 2015 Update
02-3 January 2015 Update
02-2 October 2014 Change of TM —> PM, addition in Chapter „lubrication“
02-1 July 2014 Update of Chapter „Lubrication“
02-0 June 2014 Revision of Chapter „Lubrication“
01-0 March 2014 Initial creation of this document
Table 1.1 Version management
1.1.1 Version management
1.1.2 Requirements
We assume that
| operating personnel are trained in the safe operation practices for HIWIN linear guideways and have read and under-
stood these assembly instructions in full;
| maintenance personnel maintain and repair the HIWIN linear guideways in such a way that they pose no danger to
people, property or the environment.
1.1.3 Availability
These assembly instructions must remain constantly available to all persons who work with or on the HIWIN linear
guideways. The assembly instructions are also available at www.hiwin.de.
