Hiwin MG Series User Manual

8
Product description
Assembly instructions
Linear Guideways
GW-04-0-EN-1910-MA
3. Product description
3.1 Order code of the linear guideways
3.1.1 Order code for block (unmounted)
None: Standard
E2: Version with oil tank
Accuracy class:
C, H, P
Dust protection:
None: Standard (SS)
ZZ, DD, KK, SW, ZWX
Length of rail [mm]
Accuracy class:
C, H, P, SP, UP
Rail mounting:
R: From above
T: From below
Preload ID:
Z0, ZA, ZB
Block mounting:
A: From above
C: From below
HG W 25 C C Z0 H ZZ E2
HG R 25 R 1200 H
Series
Series
Block type:
W: Flange block
H: Square block
L: Low square block
Rail
Size
Size
Load type:
S: Medium load
C: Heavy load
H: Super heavy load
3.1.2 Order code for rail (unmounted)
