– 7 –
Fig. 7 Fig. 8
GASKET INSPECTION (FIG. 9)
The recommended interval between inspections shall not exceed six months for components that are
detached for cleaning and sanitizing (all the gaskets in the images).
The inspections must be made by the manufacturer or its authorized service agent.
The slicer must be removed from service until repaired by the manufacturer or its
authorized service agent if any gasket or seal is found to be damaged, or missing.
PROTECTION ON
THE SWITCH
GASKET
BETWEEN THE
PRODUCT TABLE
AND THE
THUMB GUARD
GASKET BETWEEN
THE PRODUCT TABLE
AND THE EXTENSION
GASKET BETWEEN
THE PRODUCT TABLE
AND THE SUPPORT
GASKET BETWEEN THE
HANDLE AND THE
PRODUCT TABLE SUPPORT
GASKET BETWEEN HANDLE/SPACER
AND SPACER/MEAT PUSHER
Fig. 9

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Hobart EDGE Series and is the answer not in the manual?

Hobart EDGE Series Specifications

General IconGeneral
OperationManual
ConstructionStainless steel
TypeSlicer
Power1 HP
Dimensions26 3/4" H x 28 3/8" W x 27 1/4" D
