. A complete Parts List is available at www.HobartWelders.com
OM-925 Page 23
Notes
16 Gauge (.063 in.)
22 Gauge (.031 in.)
24 Gauge (.025 in.)
20 Gauge (.037 in.)
18 Gauge (.050 in.)
14 Gauge (.078 in.)
1/8 in. (.125 in.)
3/16 in. (.188 in.)
1/4 in. (.25 in.)
5/16 in. (.313 in.)
3/8 in (.375 in.)
1/2 in (.5 in)
MATERIAL THICKNESS REFERENCE CHART

Table of Contents

Other manuals for Hobart Handler 140

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Hobart Handler 140 and is the answer not in the manual?

Hobart Handler 140 Specifications

General IconGeneral
Input Voltage115V
Welding Amperage Range25-140 A
Duty Cycle20% @ 90A
Wire Feed Speed Range40-700 IPM
Weldable MaterialsMild Steel, Stainless Steel, Aluminum
Weight57 lbs
ProcessesMIG (GMAW), Flux-Cored (FCAW)
Input Current20A
Welding Thickness24 ga. - 1/4 in.
Input PhaseSingle Phase
Maximum Open Circuit Voltage28V
Wire Size Range0.023 - 0.035 in
