OM-925 Page 32
SECTION 9 − MIG WELDING (GMAW) GUIDELINES
mig1 2009−12
Wire Feeder/
Power Source
Workpiece
Gun
Regulator/
Flowmeter
Gas
Shielding Gas
Work Clamp
9-1. Typical MIG Process Connections
! Weld current can damage
electronic parts in vehicles.
Disconnect both battery
cables before welding on a
vehicle. Place work clamp as
close to the weld as possible.
Ref. 801 909-A
