Hobart Handler 175 User Manual

OM-944 Page 9
SECTION 2 – SPECIFICATIONS
2-1. Specifications
A. 115 VAC Model
Rated Welding
Output
Amperage
Range
Maximum Open-
Circuit Voltage
DC
Amperes Input at
Rated Load Output
115 V, 60 Hz, Single-
Phase
KVA KW
Weight
W/ Gun
Overall
Dimensions
90 A @ 19 Volts DC,
20% Duty Cycle
63 A @ 21 Volts DC,
20% Duty Cycle*
30 – 135
28
20
15*
2.90
2.20*
2.50
1.77*
55 lb
(25 kg)
Length: 18-7/8 in
(479 mm)
Width: 10-5/8 in
(270 mm)
Height: 12-3/8 in
(314 mm)
Solid/
Stainless
Flux Cored/
Aluminum
Wire Feed Speed Range
Wire Type
And Dia
.023 – .030 in
(0.6 – 0.8 mm)
.030 – .045 in
(0.8 – 1.1 mm)/
.030 – .035 in
(0.8 – 0.9 mm)
370 – 840 IPM (9.2 – 21.8 m/min) At No Load
50 – 800 IPM (1.3 – 20.3 m/min) Feeding Wire
* CSA Rating
B. 230 VAC Model
Rated Welding
Output
Amperage
Range
Maximum Open-
Circuit Voltage
DC
Amperes Input at
Rated Load Output
230 V, 50/60 Hz,
Single-Phase
KVA KW
Weight
W/ Gun
Overall
Dimensions
130 A @ 20 Volts
DC, 30% Duty Cycle
At 60 Hz Input – 20%
Duty Cycle At 50 Hz
Input
30 – 175
30 19.5 4.60 3.75
65 lb
(29.5 kg)
Length: 18-7/8 in
(479 mm)
Width: 10-5/8 in
(270 mm)
Height: 12-3/8 in
(314 mm)
Solid/
Stainless
Flux Cored/
Aluminum
Wire Feed Speed Range
Wire Type
And Dia
.023 – .035 in
(0.6 – 0.9 mm)
.030 – .045 in
(0.8 – 1.2 mm)/
.030 – .035 in
(0.8 – 0.9 mm)
350 – 900 IPM (9.0 – 23.0 m/min) At No Load
50 – 850 IPM (1.3 – 20.3 m/min) Feeding Wire

Hobart Handler 175 Specifications

General

Input Voltage	230 V
Duty Cycle	30% at 130 A
Welding Processes	MIG (GMAW), Flux-Cored (FCAW)
Input Current	20 A
Input Phase	Single-phase
Input Frequency	60 Hz
Welding Amperage Range	25 - 175 A
Wire Feed Speed Range	40 - 700 IPM
Wire Size Capacity	4 or 8 inch spools
Output Current Range	30-175A
Wire Size Range	0.023-0.045 in
