OM-316 Page 13
Return To Table Of Contents
3-4. Selecting A Location
Ref. ST-151 556 / ST-802 105-C
1 Rating Label
Locate unit near correct input
power.
Y Special installation may be
required where gasoline or
volatile liquids are present −
see NEC Article 511 or CEC
Section 20.
18 in (457 mm) for airflow
1

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Hobart STICKMATE LX and is the answer not in the manual?

Hobart STICKMATE LX Specifications

General IconGeneral
Input Voltage230 V
Input PhaseSingle Phase
Input Frequency50/60 Hz
Welding ProcessStick (SMAW)
TypeStick Welder
Electrode Size Range1/16 in to 5/32 in
