Discovery QDR Series Technical Manual
4-39
LocalMotionMax=465000 Factory Max table position using Control Panel
LocalMotionMin=0 Factory Min table position using Control Panel
LocalMotionHomePos=208000 Factory X Center table position using Control Panel
ScanPosTolerance=25400 +/- Tolerance for Scan X Position (1 in)
[TyMotor]
SpineInitPos=503175 Factory TX center position in microns (= 8.18 inches)
FlatPos=503175 Factory TX position for Detector Flattening
LocalMotionPos=503175 Factory Y Center table position using Control Panel
ScanPosTolerance=25400 Factory +/- Tolerance for Scan Y Position (1 in)
[TzMotor]
SpineInitPos=500 Factory TZ Start Position (AP)
LatInitPos=98425 Factory TZ Start Position (LAT)
LocalMotionPos=500 Factory TZ Center Positioning Control Panel
PatientUnloadPos=500 Factory Patient Unload Position
ScanPosTolerance=3175 Factory +/- Tolerance for TZ
[AyMotor]
SpineInitPos=460000 Factory C-Arm scan start position
FlatPos=510000 Factory Detector flattening start position
FlatMoveDist=25400 Factory Detector flattening move distance
LocalMotionHomePos=460000 Factory Center C-Arm position
YTiltOffset=-127000 Factory
TBarStartPos=152400 Factory Tissue BAR Start Position
[ArMotor]
SpineInitPos=500 Factory Spine Initial Position
LateralInitPos=4980 Factory Lateral initial Position
ScanPosTolerance=60 Factory +/- Tolerance for Scanning
LocalMotionMax=60 Factory Not Max Talerance for Center
LocalMotionMin=-60 Factory Min Center Position Tolerance
[Gain] Collimator & gain selection
SpineHiGain=3,3 Factory
SpineLoGain=3,3 Factory
SpineHiGain=6,3 Factory
SpineLoGain=6,2 Factory
SpineHiGain=7,2 Factory
SpineLoGain=7,1 Factory
SpineHiGain=8,1 Factory
