Discovery QDR Series Technical Manual
5-43
Table 5-4. Lower C-Arm FRUs (Figure 5-7)
Table 5-5. Upper C-Arm FRUs (Figure 5-9 and Figure 5-10)
Table 5-6. Computer and Isolation Module
Part Number Description Used On
010-0575 X-ray Tank All
010-1547 Aperture/Filter Drum Assembly Ci, Wi
010-1549 Aperture/Filter Drum Assembly C, W, SL, A
ASY-000409 Assy, 10ma X-Ray Controller All
140-0090 C-arm Interface Board All
Part Number Description Used On
010-0682 Assy, Crosshair Laser Block All
030-3171 Control Panel, Discovery, 7 Button C and W
030-3127 Control Panel, Discovery, 9 Button A and SL
465-0042 Switch, Pushbutton w/LED Pnl All
465-0043 Switch, Emergency Stop Anti-Rotate All
ASY-01374 128 Channel Assy 56303 C, W, SL
010-1606 Assy, Discovery Det 216 Chan 2mm A
010-1653 64 Channel Detector Assembly Ci, Wi
ASY-00271 64 Channel Detector Assembly Newer Ci, Wi
and
replacement
for 010-1653
on older Ci,
Wi
140-0087 A/D Converter PCB Ci/Wi with
010-1653
detector
Part Number Description Used On
PWR-100-DISCRY Kit, Power, Discovery, 100V All
PWR-120-DISCRY Kit, Power, Discovery, 120V All
PWR-230-DISCRY Kit, Power, Discovery, 230V All
010-1559 Assembly, Torroid All
120-0049 Monitor, 17" SVGA All
120-0152 Mouse, P/S All
120-0161 Keyboard, P/S All
010-1545 Discovery Computer w/XP All
