HOMEGRID Stack'd Series - Stackd Series Battery Module and Base Stand

USER MANUAL
14 15
USER
Behind the right-side panels of each baery module, you’ll
nd access to a power switch, a row of dip switches and an
RS232 port. Once your system has been fully congured and
is operaonal, there should be no need to access or make
changes in this secon unless advised by HomeGrid Support for
troubleshoong or making system conguraon changes (i.e.,
expanding system).
Stack’d Series Base Stand
The base stand funcons as a stand in which the baery
modules can rest on. Addionally, the stand puts the baery
modules 7.75 inches o the ground for protecon.
Beneath the BMS, you can stack 2-8 4.8kWh baery modules
for a total capacity range of 9.6kWh to 38.4kWh. These baery
modules are made from lithium iron phosphate (LiFePO4 or
LFP), which is one of the safest lithium baery types.
Stack’d Series 4.8 kWh Baery Module
1
2
3
Address Dial Switch
RS232 Communicaons
Interface
Power Switch
Addr
RS232
OFF ON
1
2
3
For systems with mulple stacks (i.e., 2-15 stacks connected)
all stacks must all be of equal capacity (i.e., same number of
modules) for proper system conguraon and operaon.
i
