HOMEGRID Stack'd Series - Torque Requirements; Installation Location Requirements

4 5
INSTALL
INSTALL MANUAL
area is safeguarded against children and animals accessing it
and kept distant from potenal sources of heat, re, water,
ammable or explosive materials, dust, smoke uneven
surfaces, as well as grassland or so ground.
• The installaon locaon should drain properly so there is no
standing water.
• The oor should be at, level, and capable of supporng
the weight of the system.
• The ambient temperature of the area should be between
0° C to 50° C (32° F to 122° F).
• Keep the exhaust air of the inverter at least 20 inches away
from the baery.
There is no venlaon required for the Stack’d Series baery,
but due to the heat given o from the baery and inverters,
take cauon when installaon in a small space or closed o
area. Avoid areas of high salinity, humidity, or temperature.
If the ambient temperature is outside the operang
range the baery pack will stop operang to protect
itself. The opmal temperature range for the baery
pack to operate is 0°C to 55°C. Frequent exposure
to harsh temperatures may reduce the performance
and life of the baery pack.
Please handle with care. Do not ulize a product
that has been dropped, incurred water damage,
or been subjected to a signicant impact force, as
doing so may give rise to potenal safety hazards,
including cell leakage and the risk of electric
shock. Contact HomeGrid immediately if baery is
damaged.
Torque Requirements
Installaon Locaon Requirements
The HomeGrid Stack’d Series is recommended to be installed
indoors or in accordance with local code ordinances for your
area (Contact your HomeGrid Rep for addional guidance). If
installing outdoors, please ensure you follow the guidelines
indicated below to protect the system in accordance with
warranty requirements.
• In all cases, the baery should be installed in a sheltered
locaon that is protected from direct exposure to sunshine,
rain, or snow for long periods of me. Do not install in
direct sunlight�
• The proprietary outdoor case will not protect from extreme
temperatures. If using the outdoor case, do not install in
direct sunlight�
• It is essenal to ensure that the Stack’d Series installaon
Screw Type Screwdriver Torsion
M3*12 5mm Phillips
0.55 ± .055 N.m
4.87 in-lb ± 0.49 in-lb
M4*12 5mm Phillips
1.20 ± 0.12 N.m
10.62 in-lb ± 1.06 in-lb
M5*16 5mm Phillips
2.80 ± 0.28 N.m
24.78 in-lb ± 2.48 in-lb
M8*18 M8 Socket
12 ± 1.2 N.m
106.21 in-lb ± 10.62 in-lb
