HOMEGRID Stack'd Series - BACKUP OPTIONS; Whole Home Backup (Line Side Tap); Whole Home Backup (Load Side Tap)

USER MANUAL
18 19
USER
Whole Home Backup (Load Side Tap)
When a load side tap is used, the solar power system is
connected to the electrical distribuon system aer the main
breaker panel. Depending on the home’s structure, this design
may be necessary. In this case, another separate breaker panel
is ulized within the solar system, carrying all the electrical
loads in that home. In this scenario, when o-grid, or during an
electrical grid outage, the addional main breaker panel carrying
all loads will be supplied power from the baery.
MAIN BREAKER PANEL
(ALL LOADS)
MAIN BREAKER PANEL
SOLAR
HYBRID INVERTER
UTILITY METER
GRID
OPTIONAL GENERATOR
HOMEGRID STACK’D
MAIN METER COMBO
Whole Home Backup (Line Side Tap)
BACKUP OPTIONS
Depending on the design of the system, the HomeGrid Stack’d
Series is able to parally or fully back up electrical circuits in
small homes or even large commercial buildings. Described
below are some general ways in which the HomeGrid Stack’d
Series baery is electrically congured into the typical
residenal home for whole home, or paral home backup.
Note that all scenario’s described below involve an electrical
grid connecon, though connecon to the electrical grid is not
necessary for funconal operaon. Addionally, in all cases,
“smart load management” equipment may be incorporated into
these systems.
A line side tap allows for the direct connecon of a solar power
system to the electrical grid without passing through the main
breaker panel. In this scenario, when o-grid, or during an
electrical grid outage, the home’s exisng main breaker panel
carrying all loads will be supplied power from the baery.
MAIN BREAKER PANEL
(ALL LOADS)
SOLAR
HYBRID INVERTER
UTILITY METER
GRID
OPTIONAL GENERATOR
HOMEGRID STACK’D
