INSTALL
INSTALL MANUAL
Each system will include posive and negave baery
terminal lugs (measuring 3/8 inches, suitable for 4/0 cable).
These terminal lugs do not come connected to a cable. Make
sure to use the correct cable gauge for the intended system
conguraon being installed (Use 4/0 cable to ancipate
potenal system expandability), along with the supplied baery
terminal lugs. While the distance limits may vary per installaon,
ancipate a drop in voltage aer 20 feet.
Baery Cable Guide
1 in (25.4 mm)
3/8 in
(10 mm)
4/0 MAX
Distance Range:
0’-20’ : 4/0
Aer receiving the system, please ensure that all the following
components are not lost or damaged. Contact HomeGrid
Support if any components are missing or damaged.
Included Package Contents
BMS Base
4.8 kWh Baery
Module
Controller Fixing
Bracket x2
Baery Terminal
Lugs x2 RJ45 Wire x2
Grounding/Fixed
Frame Antenna
Posive and Negave
Terminal Busbars x2
M3*12 x 3 M4*12 x 4 M5*16 x 6
M8*18 x 2
